Ajax StreetSiren DoubleDeck Fibra

Not yet reviewed
Product Code: AJXF-SSDD-51650
Information

This is the device of the Fibra wired product line. To purchase, install and administer such devices, you need to be an accredited partner, undergo training and gain access.

Wired siren with a clip lock for a branded faceplate. Designed for outdoor and indoor use.

Additional promotion of security services

StreetSiren DoubleDeck is designed not only to inform users about alarms and events but also to advertise security services with a front plastic panel - Brandplate. Security service providers can print their logo and contact information on the front panel. Located at the building outside, it will serve as an additional marketing channel that reaches new customers: neighbours and visitors.

Features

  • IP54
  • Promotion of security of installation services
  • Adjustable volume of alarms and notifications
  • Battery for additional power supply during alarm
  • Fibra wired connection: power adjustment, two-way communication, TDMA, encryption
  • Security mode and delays indication
  • Power consumption up to 0.37 W
  • Fibra line length up to 2,000 m
  • Informative in-app notifications
  • Adjustable alarm duration - 3 s to 3 min
  • Chime feature
  • Remote control and configuration

Technical Specifications

COMPATIBILITY

  • Compatible hub models: Hub Hybrid (2G), Hub Hybrid (4G)

COMMUNICATION

  • Fibra communication technology: Proprietary wired communication technology. Fibra combines the reliability of wires with the freedom of radio connection. It features:
    • Two-way communication.
    • Advanced anti-sabotage.
    • Instant notifications.
    • Remote configuration via the Ajax apps.
  • Line connection: 4-core cable
  • Fibra line length: up to 2,000 m. When using the U/UTP cat.5 twisted pair.
  • Encrypted communication

KEY FEATURES

  • Alarm type: acoustic and LED. Buzzer and LED frame.
  • Alarm volume: from 85 to 113 dB at a distance of 1 m. Adjusted by PRO or user with admin rights in the Ajax app.
  • Alarm duration: from 3 s to 3 min. Adjusted by PRO or user with admin rights in the Ajax app.
  • Siren sound frequency: 3.5 ± 0.5 kHz
  • Chime: The siren makes a special sound to notify that the opening detectors are triggered when the system is disarmed.
  • Events indication:
    • Alerts.
    • Entry/exit delays.
    • Security mode.
    • Security mode changing.
    • After-alarm indication.

RECOMMENDATIONS

  • The siren is designed for indoor and outdoor use. Recommended installation height is 2.5 m and higher.

CUSTOMIZED BRANDED FACEPLATE

  • Brandplate: Security service providers can print their logo and contact information on the siren’s front panel.

RECOMMENDATIONS

  • Brandplate is sold separately from street sirens. To place an order, reach out to your regional Ajax partner. You can also compose a faceplate design in the Brandplate constructor.

ANTI-SABOTAGE PROTECTION

  • Tampering alarm: 1Sends notification if anyone tries to detach the siren from its surface or remove the device from the mounting panel.
  • Protection against forgery: Device authentication

POWER SUPPLY

  • Fibra line power supply: 7-30 V⎓, up to 1.2 W. The siren is powered by the control panel.

ENCLOSURE

  • Dimensions: 198.5 × 198.5 × 59 mm
  • Weight: 516 g
  • Operating temperature range: from -25°C to +60°C
  • Operating humidity: up to 95%
  • Protection class: IP54

COMPLETE SET

  • StreetSiren DoubleDeck Fibra
  • SmartBracket mounting panel
  • Installation kit
  • Quick Start Guide
Specifications
  • Brand:
    Ajax Fibra
  • Product Code:
    AJXF-SSDD-51650
  • Weight:
    0.516kg
Product Code: AJXF-SSDD-51650
