Reyee 5GHz Dual-stream 802.11ac 5km Wireless Bridge

Features

• RG-EST350 V2 can easily transmit data from 5KM away in real time
• Factory-paired bridges for long-distance installation, without complex alignment
• IP54 Weatherproof, -30℃~65℃ guarantee stable operating
• Support maximum 45 * 2MP cameras loading at 3KM, 20 * 2MP cameras loading at 5KM
• Visually Intuitive statistics monitoring on Ruijie cloud, easy maintenance at remotely

Technical Specifications

• Wi-Fi Standards: Wi-Fi 5 (IEEE 802.11ac. Wave2)
• MIMO: 2x2, MU-MIMO
• Max. Wireless Speed: 5 GHz: 867 Mbps
• Antenna Gain: Directional, 15dBi
• Polarization: Horizontal: 31°, Vertical: 14°
• Recommended Distance: 5 km
• Fixed Ports: 2x 10/100/1000 Base-T
• Memory / Flash: 512 MB / 8 MB
• Weatherproof: IP54
• Transmit Power: ≤400 mW (26dBm) (adjustable)
• Automatic Pairing: Yes
• Point-to-Multipoint: 1 to 3
• Management: EWeb / Cloud / APP
• Automatic Restart: Yes
• Lightning Protection: 4kV
• Power Supply: 12 VDC / 24V Passive PoE
• Power Consumption: < 10 W
• Dimensions: 230 mm x 132 mm x 48 mm
• Weight: 0.5 kg
• Operating Temperature: -30°C ~ 65°C (-22°F ~ 149°)
• MTBF: >400000H
• Certifications: CE, RoHS
• Warranty: 3 Years
